JETWAY P4XFCU - Hardware Installation

6
JBAT CMOS RAM Clear 3-pin Block P.7
JP1 Keyboard Power On Enable/Disabled 3-pin Block P.7
Connectors
Connector Name Description Page
ATXPWR ATX Power Connector 20-pin Block P.12
ATX12V ATX 12V Power Connector 4-pin Block P.12
ATXP9 ATX P9 Power Connector 6-pin Block P.13
PS2KBM PS/2 Mouse & PS/2 Keyboard
Connector
6-pin Female P.13
CN1/LAN USB2.0/LAN Port Connector 4-pin Connector
RJ45 LAN Connector
P.13
COM
_
LP Parallel Port Connector 25-pin Female P.13
AUDIO
_
GAME Audio/Game Connector 3 phone jack+15-pin Connector P.13
COM1/COM2 Serial Port COM1/2 Connector 9-pin Connector P.13
FDD Floppy Driver Connector 34-pin Block P.14
IDE1/IDE2 Primary/Secondary IDE Connector 40-pin Block P.14
Headers
Header Name Description Page
AUDIO SPEAKER, MIC header 9-pin Block P.15
USB1,USB2 USB2.0 Port Headers 9-pin Block P.15
1394A/1394B
(for P4XFCZ)
1394 port headers 9-pin Block P.15
HD-LED IDE activity LED 2-pin Block P.15
RESET Reset switch lead 2-pin Block P.15
SPEAK PC Speaker connector 4-pin Block P.16
PWR-LED Power LED 2-pin Block P.16
PWR-BTN Power switch 2-pin Block P.16
WOL Wake On-LAN Headers 3-pin Block P.16
SFAN1, SYSFAN,CPUFAN FAN Headers 3-pin Block P.16
IR IR infrared module Headers 5-pin Block P.17
CD
_
IN CD Audio-In Headers 4-pin Block P.17
Expansion Sockets
Socket/Slot Name Description Page
ZIF Socket 478 Pin CPU Socket 478-pin mPGA CPU Socket P.9
SDR1 SDRAM Module
Socket
168-pin SDR SDRAM Module
Expansion Socket
P.9
DDR1, DDR2 DDR Module Socket 184-pin DDR Module expansion Socket P.9
PCI1 ∼ PCI5
PCI Slot 32-bit PCI Local Bus Expansion slots P.10
AGP AGP 4X Mode Slot AGP Expansion Slot P.11
Chapter 2
Hardware installation
