JF Digital MX-Pro - MX-Series Specifications; MX-1 and MX-Pro Performance Comparison

MX-Series Specifications
Configuration
Specifications
Operating System
Android7.1 + Custom Audio Framework
CPU
4 Core CPU
RAM 2GB DDR3
ROM 64GB eMMC
Screen 8-Inch Touchscreen
USB USB-OTG, supports hard drives up to 8TB
TF Card Supports TF-Cards up to 256GB
WiFi/ BT 2.4/5GHz , AC + Bluetooth 4.1
Ethernet 100/1000Mbps
Update TF-Card, OTA (over the air) update
Protocol DLNA, Airplay 1, Samba
Supported
Audio
Formats
DSD64/128/256/512 (dsf,dff,dst) “iso”
DSD 2-channel, Multi-channel converting to 2-
channels
WAV: 64bit/768kHz, DXD: 24bit/384K
APE Fast/High/Normal: 384kHz/24bit
AIFF (Apple Lossless): 384kHz/24bit
Mp3, FLAC, WMA, AAC, and many more...
Output Socket
USB 32bit/384kHz, native DSD512, Dop128
Coaxial 24bit/192kHz, Dop64
Optical 24bit/192kHz, Dop64
AES/EBU 24bit/192kHz, Dop64
I2S 32bit/384kHz, native DSD256, Dop128
D/A Analog output
32bit/384kHz, DSD256 Native, Dop128
USB Input
(XMOS)
Output Level 2.2Vrms
10 Hz-40kHz (±1dB)
Frequency
Response
THD ≤0.002%
SNR ＞115dB
Dynamic Range ＞120db
Available Colours silver / black / gold
220*250*76 mm
Dimensions
(W/D/H)
Weight
(Net/ Gross)
4/ 4.5 kg
MX-1 & MX-Pro Performance Comparison
Output MX-1 MX-Pro Remarks MX-Pro
USB
PCM 32bit/384kHz,
DSD512 Native, Dop128
PCM 32bit/384kHz,
native DSD512, Dop128
Coaxial, optical,AES
and I2S output with low
noise phase output and
dual crystal clock.
Coaxial 16bit/44.1kHz 24bit/192kHz, Dop64
Optical No 24bit/192kHz, Dop64
AES No 24bit/192kHz, Dop64
I2S 16bit/44.1kHz
32bit/384kHz,
native DSD256, Dop128
15
