I n order to achiev e optimum ef f iciency, exhaust pipe and window kit panel must be used
to output the heat air out of room as f ollowing:
O uter Exhaust Connector
Exhaust P ipe
Window K nit P anel P anel
I nstallation M ethods :
z Stretch the exhaust pipe to be at least 1 0 0
mm, and twist it clockwise into air-outlet.
z Stretch the other end of exhaust pipe to be at
least 1 0 0 mm, and twist it clockwise into the outer
exhaust connector.
z Adjust the length of window kit panel and install it into window.
z Close the door and window , and f i
x the window kit panel to window .
