z Connect the outer exhaust connector to window kit panel.
z M ake sure the air in exhaust pipe can run smoothly.
T he exhaust pipe can be stretched to 5 0 0 mm~ 1 5 0 0
mm, which is designed based on the machine test
data. U nauthoriz ed elongation or blocking of the exhaust pipe is prohibited, since it may cause the
damage of this machine .
P O WER: U nit- O N / O F F K ey. T he moment of P ower on, buz z er giv es a sound.
z
ndicator: nit-on, P ower I ndicator turns green; U nit- O f f , P ower I ndicator is of f .
z
seconds later, all loadings are of f , W . F . I ndicator turns red to show water- f ull.
z Signal- receiv ing I ndicator: receiv e the signals f rom remote control and then send them to main
base panel.
Signal- receiv ing I ndicator
P ower I ndicator
Water- f ull I ndicator
P O WER
7
Water- f ull I ndicator: U nit- on, P ower I ndicator turns green; U nit- O f f , P ower I ndicator is of f .
Unit Body and Accessories Control Panel
P
ower I
