Jimmy HW9 Pro User Manual

¤¤¤¤¤¤
12
Chapter 6 Product Specication
Technical specication
Model No HW9 Pro
Rated Power 300W
Battery Capacity 3000mAH
Charging time 4-5H
Charger input voltage 100-240V ~ 50/60 Hz
Charger output voltage 30V 600mA
Circuit Diagram
Lithium battery
Protection
PCB
Brushless
motor
Handle switch
button PCB
Mute switch
button PCB
Loudspeaker
Micro switch
Water pump
Transfer PCB 1
Dirty water tank
Infrared sensor
PCB
Floorhead
motor
Adaptor
Fan
PTC
Display
screen PCB
Control PCB

Jimmy HW9 Pro Specifications

General

Brand	Jimmy
Model	HW9 Pro
Category	Vacuum Cleaner
Language	English
