JL Audio e112 - Rear Connection Panel; Connection Panel Layout Diagram; Input, Output, and AC Terminals; Grounded;Isolated Switch Function

CH. 2
(
R
)
Grounded
Isolated
CH. 1
(
L
)
HIGH LEVEL INPUTS
SERIAL NUMBER:
Warranty void if serial number is
removed, altered or defaced.
LINE
OUTPUTS
LL
RR
LINE
INPUTS
Built in USA
with domestic and
imported components
Page 13 | EN
|
E-Sub
EN
Rear Connection Panel (120V Model Shown)
The labeled Figure below depicts the rear panel of the E-Sub subwoofer.
The e110 and e112 have identical layouts.
Line
Inputs
page 17
Grounded/
Isolated
Switch
page 17
IEC-Style AC
Connector
page 18
Line Outputs
page 18
High Level
Inputs
page 17
