CH. 2
(R
)
Grounded
Isolated
CH. 1
(L
)
HIGH LEVEL INPUTS
SERIAL NUMBER:
Warranty void if serial numbe r is
removed, altered or defaced .
LINE
OUTPUTS
LL
RR
LINE
INPUTS
Built in USA
with domestic and
imported components
Specifications
E110
E-Sub powered subwoofer
E112
E-Sub powered subwoofer
Enclosure Type: Sealed Sealed
Driver: Single 10-inch (nominal diameter) Single 12-inch (nominal diameter)
Frequency Response (anechoic):
25-116 Hz (±1.5dB)
–3 dB at 23 Hz / 120 Hz
–10 dB at 18 Hz / 165 Hz
22-118 Hz (±1.5dB)
–3 dB at 21 Hz / 120 Hz
–10 dB at 17 Hz / 153 Hz
Effective Piston Area: 58.78 sq. in. (0.0379 sq. m) 84.4 sq. in. (0.0545 sq. m)
Effective Displacement: 131 cu. in. (2.1 liters) 235 cu. in. (3.9 liters)
Amplifier Power: 1200 watts RMS short-term 1500 watts RMS short-term
Dimensions: (H) Height x (W) Width x (D) Depth
Height Dimensions include feet.
14.24 in. x 13.5 in. x 16.51 in.
362 mm x 343 mm x 419 mm
16.23 in. x 15.50 in. x 18.39 in.
412 mm x 394 mm x 467 mm
Net Weight: 52.7 lbs. (23.9 kg) 73.5 lbs. (33.3 kg)
FEATURES
Unbalanced Inputs:
Stereo or Mono (two RCA jacks)
High-Level Inputs:
Removable 4-Pole plug and connector
Line Outputs:
Stereo or Mono (two RCA jacks)
Master Level Adjustment:
Variable from full mute to +15dB over
reference gain
Power Modes:
O, On or Automatic (Signal-Sensing)
Active Crossover:
24 dB per octave, Linkwitz-Riley,
variable from 25 Hz – 130 Hz, defeatable
Polarity:
0 or 180 degrees
Phase:
Variable from 0 – 280 degrees,
referenced to 80 Hz
Power Supply:
Regulated PWM Switching Type
Amplier Topology:
Class D Switching Type
www.jlaudio.com
10369 North Commerce Parkway • Miramar, Florida • 33025 • USA
“JL Audio”, “E-Sub”, and the JL Audio logo are registered trademarks of JL Audio, Inc.
©2022 JLAudio, Inc. • For more detailed information please visit us online at www.jlaudio.com. Product images shown are for illustrative purposes only and may differ from the actual
product. Due to continuous product development, all specifications are subject to change without notice.
