JMC RTP1000 - Controls and Indicators

Controls and Indicators
2
1 Antenna
2 Belt Clip
3 Adapter Jack
4 Battery
5 Battery Release Clip
6 PTT (Push to Talk) Key
7 Triple Watch Button (TRI)
8 Lock Button (LOCK)
9 TX Power Button (1/5W)
10 Microphone
11 Speaker MIC (Optional) Jack
12 Volume/Power Knob (VOL)
13 Squelch Knob (SQ)
14 LCD Display
15 Memory Button (MEM)
16 Scan Button (SCAN)
17 Channel Up Button (▲)
18 16/9 Button (16/9)
19 Channel Down Button (▼)
20 Speaker
TRI
1/5W
16/9
MIC
MEM
SCANLOCK
1
2
4
3
5
6
7
9
8
10
12
13
14
15
11
16
17
18
19
20
