Joby Smart Stabilizer User Manual

Sliding up-down Adjust parameters
Follow mode
Function button
Double click
Single click
Function
Triple click
Explanation
Pan Mode
/ Lock Mode
Switching camera lens It needs to be used with the App
Single tap to switch between pan mode and lock mode
Four clicks Both the pan and tilt directions can be rotatedMotion control mode
Five clicks Reset
Trigger button
Temporary Lock
Double click Reset to default
Press & Hold
Centers the camera away from the user on all 3 axes ( pan,
tilt and roll) and switches back to the default pan mode
Function Explanation
In the pan mode or follow mode, holding the trigger button
temporarily locks pan and tilt until released
Adjust phone camera parameters when using the stabilizer App
Function ExplanationControl slider
From horizontal to vertical:
(1) Hold the stabilizer horizontally parallel to the ground.
(2) Press and hold the trigger button and at the same time click once on the function button.
Form vertical to horizontal (reset):
(1) Hold the stabilizer horizontally parallel to the ground.
(2) Double click on the trigger button.
Note: The automatic rotation function works ONLY if the stabilizer is held horizontally
parallel to the ground.
4. Other controls and functions
5. Automatic rotation of the smartphone
Hold the stabilizer in horizontal
Double clicks
Press & Hold
Single click
Vertical Shooting Reset
When in follow mode you can use the joystick left/right to control
the roll axis angle (-30° ~ +30°) or up/down to control the tilt axis
angle. When in follow mode, click the function button once to
return to pan mode
After the reset succeeds or fails, you can click the function button
to restart the stabilizer
6

Joby Smart Stabilizer Specifications

General

Material	-
Bluetooth	Yes
Attachment	3/8 \
Turn angle	320 °
Product color	Black
Tilt angle range	0 - 320 °
Number of sections	1
Maximum weight capacity	- kg

Weight and Dimensions

Weight	210 g
Folded depth	118 mm
Folded width	110.5 mm
Folded length	323 mm
