Joerns® Camtec Series Bed Frames
RC 1000 Bed
© 2016 Joerns Healthcare • 6110284 RevB • 16-2016
Specifications
Safe Working Load .................. 1000 lbs
Overall Width ........................... 39½" expandable to 56½"
Overall Length ......................... 89"
Mattress Support Platform ..... Width: Adjustable 36", 40", 42", 48", and 54"
Length: 80"
Mattress Support Platform Height ..... Lowest position (from oor) 16½"
Highest position 29"
Power Requirements ............... 115 VAC 60Hz 10.5 AMP
Operating Conditions
Ambient Temperature .............. +10°C to +30°C
Relative Humidity .................... 30% to 95% Non-Condensing
Atmospheric Pressure ............ 700 hPa to 1060 hPa
Storage and Shipping Conditions
Ambient Temperature .............. -30°C to +50°C Relative
Humidity ................................... 10% to 95%
Atmospheric Pressure ............ 500 hPa to 1060 hPa
Bed Weight with Side Rails, End Boards ........ 610 lbs.
Motor Duty Cycle for Intermittent Operation .. 1 minute ON / 10 minutes OFF
Head Fowler ............................. Adjustable up to 70 degrees
Foot/Knee Gatch ...................... Adjustable up to 40 degrees
Side Rails ................................. Head end are standard, 3 position swing type
Casters ..................................... Diameter 5" ...... Width 1¼"
(3) total lock and (1) steer lock
Tread Guards ... Non-marring
Options .................................... Trapeze
Mattress
Foot Extension
Side rails, foot end
Pads or Composite Insert for Side Rails
Integrated Scale
