MNP44GBV00 Rev.1 (01-03-2006) Page 2 of 16
WARN I N G
Read these instructions carefully before using the appliance:
♦ Place the sticker on the front of the banknote reader as shown on Figure 1. The
sticker should be in place before the machine is put into operation because it
shows which banknotes are accepted and the position in which they need to be
inserted
♦ When a banknote is inserted, it is more likely to be accepted if it is inserted from
the side of the front cover as shown by the arrows in Figure 1
♦ If the banknote reader head is positioned facing up, the banknotes should be
aligned to the left side, and if the banknote reader head is facing down, the
banknotes should be aligned to the right.
Figure 1. Banknote reader head
F
Note
These instructions
can be as a whole or not,
depending on the type of machine.
