MNP44GBV00 Rev.1 (01-03-2006) Page 4 of 16
TABLE OF CONTENTS:
1. GENERAL DESCRIPTION 5
1.1 Banknote reader structure 5
1.2 Mechanical characteristics of the banknote reader 6
1.3 Dimensions of the banknote reader 7
1.4 Electronic characteristics of the banknote reader 7
2. BANKNOTE READER STATUS LEDS 8
3. USING DIP SWITCHES 9
4. TECHNICAL INFORMATION 10
4.1 Machine programming options 10
4.2 MDB communications connection 10
4.3 Dimensions for installing the banknote reader in machines 11
5. MAINTENANCE PROCEDURES 12
5.1 Sensor calibration 12
5.2 Programming banknote inhibition 12
5.3 Updating the program 12
5.4 Updating patterns 12
5.5 Cleaning the banknote reader 13
5.6 Removing banknotes from the stacker 14
6. TROUBLESHOOTING 15
i This symbol means there are more detailed explanations on this subject
elsewhere in the manual.
Ë This symbol means that the text in question refers to programming.
F This symbol indicates very important information.
