STANDARD CARTRIDGE SEALS
Installation, Operation & Maintenance Instructions
15
TYPE
4610, 4615, 4620P, 5610, 5610D, 5610L, 5610P, 5610Q, 5610VL,
5610VQ, 5611, 5611L, 5611Q, 5615, 5615L, 5615Q, 5620, 5620D, 5620P,
5620VP, 5620V, 5625, 5625P, EZ-1, FFET, SB1, SB1A, SB2, SB2A, SBW
Large Bore Dimensional Data (Inches)
D1 5610, 5610D, 5610V, 5615 5610L, 5610Q, 5610VL, 5610VQ, 5615L, 5615Q 5611 5611L, 5611Q 5620, 5620P, 5620VD, 5620VP, 5625, 5625P
Shaft
Seal
D4 D26 L90 L91 M N Turn
Dia
D4 D26 L90 L91 M N Turn
Dia
D4 D26 L90 L91 M N Turn
Dia
D4 D26 L90 L91 M N Turn
Dia
D4 D26 L90 L91 M N Turn
Dia
Size min max min min min min max min min min min max min min min min max min min min min max min min min
1.375 2.875 3.023 5.375 2.125 0.250 0.562 4.062 3.268 2.875 3.023 5.375 2.125 0.791 0.562 4.062 3.268 2.875 3.023 5.375 2.125 0.688 0.562 4.062 3.268 2.875 3.023 5.375 2.125 1.353 0.562 4.062 3.268 2.875 3.023 5.375 2.125 1.914 0.562 4.062 3.268
1.750 3.500 3.925 6.500 2.187 0.250 0.687 5.093 3.885 3.500 3.925 6.500 2.187 0.744 0.687 5.093 3.885 3.500 3.925 6.500 2.187 1.038 0.687 5.093 3.885 3.500 3.925 6.500 2.187 1.626 0.687 5.093 3.885 3.500 3.925 6.500 2.187 1.995 0.687 5.093 3.885
1.875 3.625 3.734 6.500 2.017 0.327 0.687 5.093 * 3.625 3.734 6.500 2.017 0.915 0.687 5.093 * 3.625 3.734 6.500 2.017 1.209 0.687 5.093 * ** 3.625 3.734 6.500 2.017 1.797 0.687 5.093 * 3.625 3.734 6.500 2.187 1.995 0.687 5.093 4.006
2.125 3.875 4.250 7.250 2.407 0.219 0.687 5.687 4.264 3.875 4.250 7.156 2.407 0.806 0.687 5.687 4.264 3.875 4.250 7.156 2.407 0.297 0.687 5.687 4.264 3.875 4.250 7.156 2.407 1.885 0.687 5.687 4.264 3.875 4.250 7.250 2.407 2.198 0.687 5.687 4.264
2.500 4.750 5.078 8.000 2.625 0.204 0.687 6.062 5.139 4.750 5.078 8.000 2.532 0.698 0.687 6.062 5.000 4.750 4.875 8.000 2.532 1.547 0.687 6.062 5.139 4.750 4.875 8.000 2.532 2.043 0.687 6.062 5.139 4.750 5.078 8.000 2.532 2.107 0.687 6.062 5.000
2.625 4.625 4.740 8.000 2.454 0.296 0.687 6.062 ** 4.625 4.740 8.000 2.454 0.884 0.687 6.062 ** 4.625 4.740 8.000 2.454 1.774 0.687 6.062 *** 4.625 4.740 8.000 2.454 2.362 0.687 6.062 ** 4.625 4.740 8.000 2.562 2.219 0.687 6.062 5.000
2.750 4.750 4.875 8.000 2.532 0.218 0.687 6.062 5.139 4.750 4.875 8.000 2.532 0.806 0.687 6.062 5.139 4.750 4.875 8.000 2.532 1.696 0.687 6.062 5.139 4.750 4.875 8.000 2.532 2.284 0.687 6.062 5.139 4.750 4.875 8.000 2.532 2.312 0.687 6.062 5.139
*SeaI cartridge is OD registered on the Turn Dia. of 4.125.
**SeaI cartridge is OD registered on the Turn Dia. of 5.125.
