LP69910 (12/07/2020) 3 CU FT GATOR FERTILIZER SPREADER

Removal and Storage

Removal

1. Disconnect spreader wire harness from chassis harness.

2. Unclip the spreader harness from the hitch and loop the

harness around spreader frame.

NOTE: It is recommended that two people lift the

spreader for this removal

3. Lift Lock bar (A) and slide implement outwards.

CAUTION: Disconnect electric and/or

hydraulic power and tag out if required before

servicing or performing maintenance.

4. Lift away the implement.

Storage

1. Wash spreader and allow to dry.

2. Apply dielectric grease on all the electrical connections

to prevent corrosion.

3. Cover spreader and store.
