LP69910 (12/07/2020) 3 CU FT GATOR FERTILIZER SPREADER
Installation
Spreader Assembly
1. Connect hitch mount (A) to the spreader using four 1/2
in. x 1- 1/2 in. ange bolts (B).
2. For use with 835/865 Gator, remove CAN termination
plug (C) from spreader harness and replace with
receptacle dust cap (D).
Installing Spreader
1. To aid in assembly, add grease to the slots.
NOTE: It is recommended that two people lift the
spreader for this installation.
2. Side receiver arms (A) into slots (B) until it clicks to lock
into place. Be sure that the hitch latches securely.
B
A
A
B
3. Plug the spreader harness into the chassis harness
(C). Secure the harness to the hitch using the harness
clips (D).
D
C
