LP69910 (12/07/2020) 3 CU FT GATOR FERTILIZER SPREADER
Wiring Diagram
Spreader Harness Connections
2 pin Connector
pin 1 Battery Positive
pin 2 Battery Negative
6 pin Connector
pin 1 Switched Battery Positive
pin 2 Battery Negative
pin 3 Ignition
pin 4 CAN-
pin 5 CAN+
pin 6 No Connect
Control Module Output Terminals
A Spinner Motor Negative
B Spinner Motor Positive
C Battery Negative
D Battery Positive
E Gate Actuator Negative
F Gate Actuator Positive
G No Connect
H No Connect
