42
Putting the door glass back
1.
From above insert the door glass at an angle
into the door profile at the bottom edge of
the door and lower it.
2.
Take hold of the door trim (B) at each side,
position it on the inside edge of the door
and plug the door trim(B) into the upper
edge of the door.
3
On the open side of the door trim (B)
there is a guide bar (C). This must be-
pushed
between
the outer door panel
and the guide corner(D).
The clip seal (E) must be snapped in.
