Johnson Controls
Start-Up & Operation Guide | 5586996-JSG-A-0120
83
Operation
Table 26: Menus and Submenus (Continued)
Menu Submenu Parameters Displayed / Default
Conditions for Parameters Displayed
Units / Range
Details
(Figure 31)
SF > Setup
FanOffDlyCool (Fan Off Delay for Cool)
/ 30 seconds)
seconds (0–255)
PFILT-DP (Pre-Filter Differential Pressure) iwg
FFILT-DP (Final Filter Differential
Pressure)
iwg
MaxAirow cfm (0–100,000)
UVLight-En (UV Light Installed) No, Yes
UVLight-Life (UV Light Lifetime) hours (10–20,000)
Pickup Gain 0–100
SF > Service
SupplyF-S (Supply Fan Status)
OFF-Idle, ON-Purge, ON-Gas Valve or Limit Fault,
ON, ON-Thermostat Request, ON-Fan Off Delay for
Cool, ON-Fan Off Delay for Heat, ON-Continuous Fan
Occupied Operation, ON-Normal Command, OFF-
Exceeding Duct Pressure Shutdown SP, OFF-Low
Voltage, OFF-Fan Overload Lockout, OFF-Fan VFD
Fault, OFF-Hot Water Freeze Stat, OFF-Air Proving
Switch, OFF-Minimum Off Delay, OFF-Fan On Delay
For Heat, OFF-Fan Off Delay for Cool
SF-C (Supply Fan Command) OFF, ON
SF-O (Fan % Command) %
SF-Runtime hours
SF-Starts counts
OprFanReq (Operating Fan Request) OFF, ON
FanReqSrc (Fan Request Source)
Unreliable, Local Input, Network Sensor, High
Priority, BAS Override, Input Not Available
FanVFD1-RT (Fan VFD1 Accumulated
Runtime)
hours
FanVFD1-Starts (Fan VFD1 Number of
Times On)
counts
FanVFD2-RT (Fan VFD2 Accumulated
Runtime)
hours
FanVFD2-Starts (Fan VFD2 Number of
Times On)
counts
APS (Air Proving Switch) OFF, ON
SFVFD1Flt (Supply Fan VFD 1 Fault) Normal, Alarm
SFVFD2Flt (Supply Fan VFD 2 Fault) Normal, Alarm
DA-P (Discharge Air Static Pressure) iwg
DAPHI-A (Discharge Air High Duct
Pressure)
Normal, Alarm
DA-DP (Discharge Air Differential
Pressure)
iwg
DADP-Alarm (Discharge Air VP Sensor
Alarm)
Normal, Alarm
RADP-Alarm (Return Air VP Sensor
Alarm)
Normal, Alarm
RFP-Alarm (Return Fan Pressure
Sensor Alarm)
Normal, Alarm
UVLight-Rt (UV Light Runtime) hours
