Johnson Controls GVD Series User Manual

Johnson Controls
5586996-JSG-A-0120 | Start-Up & Operation Guide
84
Table 26: Menus and Submenus (Continued)
Menu Submenu Parameters Displayed / Default
Conditions for Parameters Displayed
Units / Range
Details
(Figure 31)
SF > Service
UVLight-Service (UV Light Needs
Service)
Normal, Alarm
UVLight-Reset (UV Light Runtime Reset) OFF, Reset
UVLight-RtOvr (UV Light Runtime
Override)
hours (0–100,000)
Econ > Setup
Econ-En (Economizer Enabled For
Operation)
No, Yes
Econ-MinPos (Economizer Minimum
Position Setpoint)
% (0–100)
LowSpeedFan-MinPos (Economizer
Damper Minimum Position Low Speed
Fan)
% (0–100)
HighSpeedFan-MinPos (Economizer
Damper Minimum Position High Speed
Fan)
% (0–100)
FreeClg-Sel (Free Cooling Selection)
Dry Bulb Temperature, Differential Dry Bulb, Single
Enthalpy, Dual Enthalpy, Auto
FreeClg-Mode (Free Cooling Current
Mode)
Dry Bulb Temperature, Differential Dry Bulb, Single
Enthalpy, Dual Enthalpy, Unreliable
AllCompOff-Econ (All Compressors OFF
in Free Cooling)
No, Yes
EconOAT-SpEn (Economizer Outside
Air Temperature Enable Setpoint)
deg F (40–80)
EconOAEnth-Sp (Economizer Outdoor
Air Enthalpy Setpoint)
Btu/lb dry air (10–50)
MATClgLim (Mixed Air Temperature
Cooling Limit)
deg F (40–80)
DVent-Mode (Demand Ventilation Mode
of Operation)
Disabled, Controlled by IAQ, Diff between IAQ and
OAQ
DVentMaxEconPos (Demand Ventilation
Maximum Economizer Position)
% (0–100)
DVentIAQ-Sp (Demand Ventilation
Indoor Air Quality Setpoint)
ppm (0–5,000)
DVentDiff-Sp (Demand Ventilation
Differential Setpoint)
ppm (0–5,000)
MinOA-En (Min OA Enable) Disable, Enable
MOAFlow-Sp (Min OA Flow Setpoint) cfm (0–50,000)
MaxOAFlow (Maximum Outside Airow) cfm (0–100,000)
EconFltDetectEn (Economizer Fault
Detection Enable)
Disable, Enable
AdapTunEn (Auto Tuning Enable) Disable, Enable
IAQ-Deadband (Indoor Air Quality
Deadband)
cfm (0–3,000)
Econ >
Service
Clg-S (Cooling Status)
OFF-Idle, Thermostat Cooling, Unoccupied
Cooling, Occupied Cooling, OFF-OAT Lockout,
OFF-Disabled, OFF-Lockout, OFF-Low Supply
Voltage, OFF-Low Ambient, OFF-Low Ambient Pre-
Run Delay, OFF-Waiting For Changeover Delay,
OFF-Free Cooling, Comfort Ventilation
