Table 7: Status LEDs and description of LED states
LED label LED color
Normal LED
state
Description of LED states
POWER Green On Steady
Off Steady = No Supply Power. The expansion module’s
polyswitch/resettable fuse may be open. Check output wiring for
short circuits and cycle power to expansion module.
On Steady = Power Connected
FAULT Red Off Steady
Off Steady = No Faults
On Steady = Device Fault
Blink - 2 Hz = Download or Startup in progress: not ready for
normal operation
SA/FC BUS Green Blink - 2 Hz
Blink - 2 Hz = Data Transmission (normal communication)
Off Steady = No Data Transmission (N/A - auto baud not
supported)
On Steady = Communication lost; waiting to join communication
ring
EOL Amber
Off (Except on
terminating
devices)
On Steady = EOL switch in ON position
Off Steady = EOL switch in Off position
Repair information
If a controller fails to operate within its
specifications, replace the controller. For a
replacement controller, contact your Johnson
Controls representative.
Accessories
Table 8: Accessories Ordering Information
Product Code Number Description
Mobile Access Portal
(MAP) Gateway
Refer to the Mobile Access Portal Gateway Catalog Page (LIT-1900869) to identify the
appropriate product for your region.
Note: The MAP Gateway serves as a replacement for the BTCVT, which is no
longer available for purchase, but continues to be supported.
TL-CCT-0 Metasys Controller Configuration Tool (CCT) Software
MS-FCP-0 Metasys Field Controller Firmware Package Files for CCT
TP-2420 Transformer, 120 VAC Primary to 24 VAC Secondary, 20 VA, Wall Plug
Y65T31-0
Transformer, 120/208/240 VAC Primary to 24 VAC Secondary, 40 VA, Foot Mount, 8
in. Primary Leads and Secondary Screw Terminals, Class 2
Note: Additional Y6x-x Series transformers are also available. Refer to the
Series Y63, Y64, Y65, Y66, and Y69 Transformers Product Bulletin (LIT-125755) for
more information.
AS-CBLTSTAT Cable adapter for connection to 8-pin TE-6700 Series sensors
AS-XFR050-0 Power Transformer (Class 2, 24 VAC, 50 VA Maximum Output), no enclosure
AP-TBK4SA-0 Replacement SA Bus Terminal Blocks, 4-Position, Brown, Bulk Pack of 10
IOM3733 Input/Output Module Installation Guide12
