USER INTERFACE
QOLSYS CONFIDENTIAL AND PROPRIETARY
PAGE OF 16 27
PARTITION ARMING
PARTITION ARMING:
The Hash Menu on the IQ Keypad allows access to Partition Arming functionality. It may also act as a “Home”
button to back out of any button press activity and start over. See table below for a list of functions.
Press
Action
[#][1] + [Arm Stay] + [Access Code] or [Prox]
Arm Partition 1 to Stay
[#][2] + [Arm Stay] + [Access Code] or [Prox]
Arm Partition 2 to Stay
[#][3] + [Arm Stay] + [Access Code] or [Prox]
Arm Partition 3 to Stay
[#][4] + [Arm Stay] + [Access Code] or [Prox]
Arm Partition 4 to Stay
[#][1] + [Access Code] or [Prox]
Disarm Partition 1
Hold [#] for 2 Seconds
Cancels any current IQ Keypad activity or button
presses
