IQ KEYPAD OVERVIEW
EXTERIOR FRONT
QOLSYS CONFIDENTIAL AND PROPRIETARY
PAGE OF 4 27
Prox Tag Reader
(IQ Keypad Prox-PG only)
Arm Stay
Arm Away
Arm Night
Trouble
LED
Armed Status LED
Disarmed Status
LED
Fire Emergency
(1+3)
Hold for 2 sec
Police Emergency
(7+9)
Hold for 2 sec
Aux Emergency
(4+6)
Hold for 2 sec
