IQ KEYPAD OVERVIEW
EXTERIOR BACK
Retaining Screw
4 x AA Batteries
behind Back Plate
For UL2610 applications
this screw shall be used
for tamper protection
against mounting removal
Mounting
Holes
QOLSYS CONFIDENTIAL AND PROPRIETARY
PAGE OF 5 27
