Page #3 background imageLoading...
Page #3 background image
the network or field bus application are provided in tables
of this document.
Power supply
The device is powered with either a 24 VAC power
transformer or a portable power adapter that supplies 24
VDC. In North America, use a Class 2, 24 VAC power supply
with a 50 VA minimum output. Outside North America,
use a 24 VAC SELV transformer at the appropriate rating.
The minimum input voltage for the device to operate
properly is 20 VAC.
Use a dedicated power supply to the device only. Do not
connect any other loads to the power supply. Additional
loads can cause noise interference.
Ethernet port
The Ethernet port is an 8-pin RJ45 network port to connect
the device to Ethernet IP networks. The device can
connect to Ethernet networks at 100 or 10 Mbps. The
maximum cable length is 100 m (328 ft).
FC bus terminal blocks
The device has one Field Controller (FC) bus connection.
These connections use a 4-pin removable, keyed terminal
block that is labeled FC BUS-1.
The FC bus connections are isolated RS-485 ports that
communicate at 2400, 9600, 19,200, 38,400, or 76,800
baud. You can use the FC bus port to integrate the BACnet
MS/TP FC bus field controller network into the BAS
system.
The SHD (shield) connections on the FC terminal blocks
are not connected to any earth ground connection.
USB ports
The device features two USB 2.0 host (type A) ports and
one micro-USB 2.0 client port. These ports are disabled
and are for future enhancements.
Wiring
Mount the device securely before you wire it. For details,
see Mounting.
CAUTION
Risk of Property Damage.
Do not apply power to the system before checking
all wiring connections. Short circuited or improperly
connected wires may result in permanent damage to
the equipment.
Attention
Risque de dégâts matériels.
Ne pas mettre le système sous tension avant
d'avoir vérifié tous les raccords de câblage. Des
fils formant un court-circuit ou connectés de façon
incorrecte risquent d'endommager irrémédiablement
l'équipement.
WARNING
Risk of Electric Shock.
Disconnect or isolate all power supplies before
making electrical connections. More than one
disconnection or isolation may be required to
completely de-energize equipment. Contact with
components carrying hazardous voltage can cause
electric shock and may result in severe personal injury
or death.
WARNING
Risque de décharge électrique.
Débrancher ou isoler toute alimentation avant
de réaliser un branchement électrique. Plusieurs
isolations et débranchements sont peut-être
nécessaires pour -couper entièrement l'alimentation
de l'équipement. Tout contact avec des composants
conducteurs de tensions dangereuses risque
d'entraîner une décharge électrique et de provoquer
des blessures graves, voire mortelles.
Important: Use this device only as an operating
control. Where failure or malfunction of the device
could lead to personal injury or property damage
to the controlled equipment or other property,
additional precautions must be designed into the
control system. Incorporate and maintain other
devices, such as supervisory or alarm systems or
safety or limit controls, intended to warn of or
protect against failure or malfunction of the device.
JC-RTR11002-0 BACnet Router Installation Guide 3
