Johnson Controls MAP 1810 Installation Instructions

USB Port
Note: USB port functionality is not available in this
software release.
The USB port on the MAP Gateway is a 5-pin, Micro-B
peripheral serial port which conforms to the USB 2.0
standard. The MAP Gateway USB port is for connecting
to a computer for commissioning, downloading, and
retrieving data. When the MAP Gateway is connected
and powered from the USB port, FC/SA bus functions
are not available.
Note: The USB connection on the MAP Gateway is not
designed for constant use. The USB port should
be used only when needed.
Table 1: USB Port Pin Designations
Signal NamePin Number
(Both Ends
of Cable)
+5 VDC1
Data -2
Data +3
No Connection4
Ground5
Ethernet Port
The Ethernet port on the MAP Gateway is an 8-pin RJ-45
jack. The maximum allowable cable length is 100 m
(328 ft).
See the Features section for the location of the
communications terminal on the MAP Gateway.
Note: If you use the Ethernet port to connect to the
MS/TP bus, power must be supplied by an
external supply that is not the USB connection or
the SA/FC bus connection. External power supply
hardware varies by market. For information on
the external power supply provided, see the
Technical Specifications section.
External Power Supply Connections
To connect the MAP Gateway using the supplied external
power source:
1. Connect the 15 VDC output connector of the power
supply to the power supply port of the MAP Gateway.
Risk of Property Damage. Do not apply power to
the system before checking all wiring connections.
Short circuited or improperly connected wires may
result in permanent damage to the equipment.
MISE EN GARDE:
Risque de dégâts matériels. Ne pas mettre le
système sous tension avant d'avoir vérifié tous les
raccords de câblage. Des fils formant un court-circuit
ou connectés de façon incorrecte risquent
d'endommager irrémédiablement l'équipement.
2. Connect the power supply to the supplied power cord.
3. Plug the power cord into a 100-240 VAC outlet.
Important: Power should only be applied and removed
by connecting and disconnecting the power
cord from the 100-240 VAC outlet. Applying
or removing power by connecting or
disconnecting the 15 VDC connector can
damage the unit.
Risk of Electric Shock. Disconnect or isolate all power
supplies before making electrical connections. More than
one disconnection or isolation may be required to
completely de-energize equipment. Contact with
components carrying hazardous voltage can cause
electric shock and may result in severe personal injury
or death.
AVERTISSEMENT:
Risque de décharge électrique. Débrancher ou isoler
toute alimentation avant de réaliser un branchement
électrique. Plusieurs isolations et débranchements sont
peut-être nécessaires pour -couper entièrement
l'alimentation de l'équipement. Tout contact avec des
composants conducteurs de tensions dangereuses
risque d'entraîner une décharge électrique et de
provoquer des blessures graves, voire mortelles.
7Mobile Access Portal Gateway Installation Instructions
