Johnson Controls Metasys MS-NCE2560-0 User Manual

Table 12: Terminal wiring
Terminal block
label
Terminal labels Function, ratings, and
requirements
Determine wire size
and maximum cable
length
OCOMn Analog Output Signal
Common: All Configurable
Outputs defined as Analog
Outputs share a common,
which is isolated from all other
commons except the Binary
Input common.
Binary Output Signal
Common: All Configurable
Outputs defined as Binary
Outputs are isolated from all
other commons, including
other Configurable Output
commons.
Same as (Configurable)
OUTn.
The following table defines cable length guidelines for the various wire sizes can may be used for
input and output wiring.
Table 13: Cable length guidelines for recommended wire sizes
Guideline Wire size/gauge and type Maximum cable
length and type
Assumptions
1.0 mm (18 AWG) stranded copper 457 m (1,500 ft) twisted
wire
0.8 mm (20 AWG) stranded copper 297 m (975 ft) twisted
wire
0.6 mm (22 AWG) stranded copper 183 m (600 ft) twisted
wire
A
0.5 mm (24 AWG) stranded copper 107 m (350 ft) twisted
wire
100 mV maximum
voltage drop
Depending on the
cable length and the
connected input or
output device, you
may have to define
an offset in the setup
software for the input
or output point.
1.0 mm (18 AWG) stranded copper 229 m (750 ft) twisted
wire
0.8 mm (20 AWG) stranded copper 137 m (450 ft) twisted
wire
0.6 mm (22 AWG) stranded copper 91 m (300 ft) twisted
wire
B
0.5 mm (24 AWG) stranded copper 61 m (200 ft) twisted
wire
100 mV maximum
voltage drop
Depending on the
cable length and the
connected input or
output device, you
may have to define
an offset in the setup
software for the input
or output point.
25NCE25 Installation Instructions
