885616-UTG-A-0812
2 Johnson Controls Unitary Products
MODEL NUMBER NOMENCLATURE
Touch Screen Master & Sensor
S1 - T TS C C 01 A
Zone Display
S1 - T C ZS D 01 A
Zone Panel
S1 - T C ZCB 01 A
Zone Sensor
S1 - T C ZS N 01 A
PRODUCT DATA INFORMATION
Physical Characteristics
Dimensions:
See drawing
Appearance:
Plastic, white color, textured
Electrical Characteristics/Communication
Input Volts/Amps 24VAC:
Each device in the communicating system has a four-pin con-
nector labeled A+, R, C, B-. It is recommended that the follow-
ing color code be used when wiring each device:
A+ Green = Data A+
R Red = 24VAC (Hot)
C Black = 24VAC (Com)
B- White = Data B-
Environmental Requirements
Operating Temperature/Relative Humidity:
User interface and all sensors: 32F to 104F / 0C to 40C, 95%
RH non-condensing.
Storage Temperature/Relative Humidity:
User interface: -40F to 134F /-40C to 56.7C, 95% RH non-con-
densing.
Wiring Requirements
Power supply:
Dedicated 24VAC, 40 va, 60 Hz, via indoor equipment A+, R, C,
B- Connector. Isolated transformer, field supplied.
Wiring material:
Standard thermostat wire 18 to 24 gauge.
Feature Specifications
• Temperature set point range: 40F to 90F / 4.4C to 32.2C
• Separate heat and cool setpoints
• Programming days: 7 day
• Programming periods:
2 Periods: Day, Away
3 Periods: Day, Away, Sleep
4 Periods: Awake, Away, Return, Sleep
• Non-Programmable
• Auto changeover (may be disabled)
• Programmable fan (installer selectable)
• Humidity Sensor Offsets
• Smart Recovery (in heating and cooling)
• Copy functions: Copy period, day and zone
• Permanent memory
• Humidity display and control
• Temperature sensor offsets (indoor and outdoor)
S1 Source 1
T Tag in a bag
TS Touch Screen
C Communicating
C Control
01 1st Generation
A Revision A
S1 Source 1
T Tag in a bag
C Communicating
ZS Zone Sensor
DWith Display
01 1st Generation
A Revision A
S1 Source 1
T Tag in a bag
C Communicating
ZCB Zone Control Board
01 1st Generation
A Revision A
S1 Source 1
T Tag in a bag
C Communicating
ZS Zone Sensor
NNo Display
01 1st Generation
A Revision A
Compatible Communicating Products
Model Description YORK COLEMAN LUXAIRE
Air Conditioning CZF, CZH AC6, AC8 AL6, AL8
Heat Pumps YZF, YZH HC6, HC8 HL6, HL8
Gas Furnaces YPLC, YP9C CPLC, CP9C LPLC, LP9C
Air Handlers MV, AV*, AHV MV, AV*, AHV MV, AV*, AHV
