S350A Temperature, S351A Humidity, and S352A Pressure Stage Modules Product/Technical Bulletin
A
pplication
The S350A, S351A, and S352A Stage Modules
receive power, setpoint, and sensor input from the
respective System 350 control modules. When
connected, the individual modules act as a multistage
control system.
The maximum number of stages that can be used in a
system varies with the control module type
(temperature, humidity, or pressure) and stage module
design.
Refer to Table 1 or Table 2 to determine the maximum
number of stages that may be used with each control
module. When mixing stage module designs, always
use the lower number.
Note: When using an external transformer, the
Y65 Series or other 40 VA Class 2
transformers are recommended.
Table 1: Maximum Number of Add-on
Modules when Powered by a Y350R
Power Module
Stage
Module
Display
Module
Control
Module
No. Model
Numbers
No. Model
Number
A350A
A350B
A350E
9
6
4
S350As or S350Cs
S350As or S350Cs
with 1 S350P
S350As or S350Cs
with 2 S350Ps
1 D350
A350P
4
2
S350As or S350Cs
S350As or S350Cs
with 1 S350P
1 D350
A350R
A350S
9
6
4
S350As or S350Cs
S350As or S350Cs
with 1 S350P
S350As or S350Cs
with 2 S350Ps
2 D350s
W351A
5 S351As 1 D351
W351P
4 S351As 1 D351
P352AB
5 S352As 1 D352A
P352PN
4 S352As 1 D352A
Table 2: Maximum Number of Add-on
Modules when Powered by an External
Transformer
Stage
Module
Display
Module
Control
Module
No. Model
Numbers
No. Model
Number
A350A
A350B
A350E
9
8
7
S350As or S350Cs
S350As or S350Cs
with 1 S350P
S350As or S350Cs
with 2 S350Ps
1 D350
A350P
9
8
7
S350As or S350Cs
S350As or S350Cs
with 1 S350P
S350As or S350Cs
with 2 S350Ps
1 D350
A350R
A350S
9
8
7
S350As or S350Cs
S350As or S350Cs
with 1 S350P
S350As or S350Cs
with 2 S350Ps
2 D350s
W351A
9 S351As 1 D351
W351P
9 S351As 1 D351
P352AB
9 S352As 1 D352A
P352PN
9 S352As 1 D352A
Notes: This bulletin only refers to the S350A, S351A,
and S352A Stage Modules.
For information on the S350C refer to the
System 350
TM
S350C Temperature Slave
Stage Module Product/Technical Bulletin
(LIT-930084).
For information on the S350P refer to the
System 350
TM
S350P Proportional Plus
Integral Temperature Stage Module
Product/Technical Bulletin (LIT-930086).
For information on the D350, D351 and D352
refer to the
System 350
TM
D350 Display
Modules Product/Technical Bulletin
(LIT-930070)
.
