Johnson Controls TCGD30 User Manual

415571-UTG-C-0309
6 Johnson Controls Unitary Products
COOLING CAPACITY - With High Efficiency Motor Furnaces
UNIT
MODEL
FURNACE
MODEL
COIL
MODEL
1
W
COOLING
RATED
CFM
Net MBH
SEER EER
TOTAL SENS.
13 SEER HP WITH VARIABLE SPEED FURNACES
2
TCGD30S4(3,4)S1
T*(8,L)X*A12 FC/MC/PC32A 14 970 29.2 21.4 13.20 11.00
T*(8,L)X*B12 FC/MC/PC35B 17 1120 30.0 22.8 14.00 11.50
T*(8,L)X*C16 FC/MC/PC35C 21 1105 30.0 22.8 14.00 12.00
T*(8,L)X*C20 FC/MC/PC35C 21 850 28.8 20.6 14.00 12.00
T*9X*B12 FC/MC/PC35B 17 1085 29.8 22.8 14.00 12.00
T*9X*C16 FC/MC/PC35C 21 1075 29.8 22.4 14.00 12.00
T*(8,L)X*A12 FC/MC/PC37A 14 1105 30.0 22.9 13.80 11.50
T*(8,L)X*B12 FC/MC/PC43B 17 1125 30.0 22.9 14.00 12.00
T*(8,L)X*C16 FC/MC/PC43C 21 710 28.2 19.3 14.00 12.00
T*(8,L)X*C20 FC/MC/PC43C 21 870 29.6 21.2 14.00 12.00
T*9X*B12 FC/MC/PC43B 17 1095 30.0 22.9 13.80 11.50
T*9X*C16 FC/MC/PC43C 21 1055 30.0 22.9 14.00 12.00
T*9X*C20 FC/MC/PC43C 21 720 28.2 19.3 14.00 12.00
TCGD36S4(3,4)S1
T*(8,L)X*A12 FC/MC/PC37A 14 1290 35.2 25.4 13.30 11.25
T*(8,L)X*B12 FC/MC/PC43B 17 1300 35.2 25.4 13.30 11.25
T*(8,L)X*C16 FC/MC/PC43C 21 1175 35.2 24.8 14.00 11.50
T*(8,L)X*C20 FC/MC/PC43C 21 1250 35.6 25.6 13.80 11.70
T*9X*B12 FC/MC/PC43B 17 1270 35.2 25.4 13.25 11.25
T*9X*C16 FC/MC/PC43C 21 1260 35.4 25.4 13.45 11.40
T*9X*C20 FC/MC/PC43C 21 1185 35.0 24.6 13.55 11.40
T*(8,L)X*C16 FC/MC/PC48C 21 1185 35.6 25.2 14.00 11.50
T*(8,L)X*C20 FC/MC/PC48C 21 1270 35.8 25.8 14.00 11.50
T*9X*C16 FC/MC/PC48C 21 1280 35.8 25.8 13.70 11.50
T*9X*C20 FC/MC/PC48C 21 1205 35.4 25.0 13.70 11.50
T*9X*D20 FC/MC/PC48D 24 1240 35.4 25.0 13.70 11.50
T*(8,L)X*C16 UC48C 21 1185 34.2 24.8 13.50 11.50
T*(8,L)X*C20 UC48C 21 1300 34.8 25.4 13.50 11.50
T*9X*C16 UC48C 21 1280 34.6 24.8 13.15 11.20
T*9X*C20 UC48C 21 1205 34.0 24.6 13.25 11.20
T*9X*D20 UC48D 24 1240 34.0 24.6 13.30 11.25
TCGD42S4(3,4)S1
T*(8,L)X*B12 FC/MC/PC43B 17 1300 42.0 29.0 13.50 11.50
T*(8,L)X*C16 FC/MC/PC43C 21 1475 42.0 29.9 13.50 11.50
T*(8,L)X*C20 FC/MC/PC43C 21 1415 42.0 29.5 13.50 11.50
T*9X*B12 FC/MC/PC43B 17 1270 42.0 29.0 13.50 11.50
T*9X*C16 FC/MC/PC43C 21 1410 42.0 29.6 13.30 11.00
T*9X*C20 FC/MC/PC43C 21 1400 42.0 29.6 13.50 11.00
T*(8,L)X*C16 FC/MC/PC48C 21 1360 42.0 29.5 13.80 11.50
T*(8,L)X*C20 FC/MC/PC48C 21 1475 42.0 30.1 14.00 11.50
T*9X*C16 FC/MC/PC48C 21 1425 42.0 29.3 13.50 11.50
T*9X*C20 FC/MC/PC48C 21 1420 42.0 29.3 13.50 11.50
T*9X*D20 FC/MC/PC48D 24 1435 42.0 29.7 13.50 11.50
T*(8,L)X*C16 UC48C 21 1400 42.0 29.4 13.50 11.00
T*(8,L)X*C20 UC48C 21 1515 42.0 30.0 13.50 11.00
T*9X*C16 UC48C 21 1425 41.5 29.2 13.30 11.00
T*9X*C20 UC48C 21 1420 42.0 29.4 13.20 11.00
T*9X*D20 UC48D 24 1435 42.0 29.4 13.40 11.00
For Notes See Page 7.
