TCGD48S4(3,4)S1
T*(8,L)X*C16 FC/MC/PC48C 21 1600 48.0 34.4 13.30 11.00
T*(8,L)X*C20 FC/MC/PC48C 21 1660 48.0 34.4 13.20 11.00
T*9X*C16 FC/MC/PC48C 21 1565 48.0 34.8 13.10 11.00
T*9X*C20 FC/MC/PC48C 21 1615 48.0 34.4 13.20 11.00
T*9X*D20 FC/MC/PC48D 24 1635 48.0 34.8 13.20 11.00
T*(8,L)X*C16 FC/PC60C 21 1605 48.0 34.6 13.30 11.00
T*(8,L)X*C20 FC/MC/PC60D 21 1595 48.0 34.8 13.30 11.00
T*9X*C16 FC/PC60C 21 1575 48.0 34.6 13.30 11.00
T*9X*C20 FC/PC60C 21 1625 47.0 34.6 13.40 11.00
T*9X*D20 FC/MC/PC60D 24 1490 47.5 33.8 13.20 11.00
T*9X*C16 FC/PC60C 21 1575 47.0 33.8 13.10 11.00
T*9X*C20 FC/PC60C 21 1625 47.0 33.8 13.10 11.00
TCGD60S4(3,4)S1
T*(8,L)X*C16 FC/PC60C 21 1605 56.5 37.8 13.50 11.00
T*(8,L)X*C20 FC/MC/PC60D 21 1690 57.0 37.8 13.50 11.00
T*9X*C16 FC/PC60C 21 1575 56.0 37.8 13.30 11.00
T*9X*C20 FC/PC60C 21 1560 56.0 37.8 13.30 11.00
T*9X*D20 FC/MC/PC60D 24 1630 56.5 37.8 13.30 11.00
T*9X*C20 FC/MC/PC60D 21 1645 56.5 37.8 13.30 11.00
T*(8,L)X*C20 FC/MC62D 21 1665 57.0 37.8 13.50 11.00
T*(8,L)X*C16 UC60C 21 1640 56.0 37.2 13.00 11.00
T*(8,L)X*C20 UC60D 21 1735 56.5 38.5 13.00 11.00
T*9X*C16 FC/PC60C 21 1575 56.0 37.2 13.00 11.00
T*9X*C20 FC/PC60C 21 1560 56.0 37.2 13.00 11.00
T*9X*D20 UC60D 24 1630 56.0 37.2 13.00 11.00
T*(8,L)X*C20 UC60D 21 1735 56.5 38.5 13.00 11.00
T*9X*C20 UC60D 21 1645 56.0 37.2 13.00 11.00
1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.
2. Variable speed furnaces have B.O.D (Blower on Delay) standard.
COOLING CAPACITY - With High Efficiency Motor Furnaces (Continued)
UNIT
MODEL
FURNACE
MODEL
COIL
MODEL
1
W
COOLING
RATED
CFM
Net MBH
SEER EER
TOTAL SENS.
13 SEER HP WITH VARIABLE SPEED FURNACES
2
