TEC26x7-4 Series BACnet® MS/TP Networked Thermostat Controllers with Two Outputs Installation
Instructions
Deadband Sets the minimum deadband
between the heating and cooling
setpoints.
Default: 2.0F°/1.0C°
Range: 2.0F°/1.0C° to 5.0F°/2.5C° (adjustable in 1.0F°/0.5C°
increments)
Cal RS Sets the desired room air sensor
calibration (offset). The offset can
be added to or subtracted from the
actual displayed room temperature.
Default: 0.0F°/0.0C°
Range: -5.0F°/-2.5C° to 5.0F°/2.5C° (adjustable in 1.0F°/0.5C°
increments)
Aux cont Determines the auxiliary contact
function and configuration.
Default: 0
(0) Not used,
or used for
reheat
If the Sequence of Operation is set to
reheat (2, 3, or 5), ignore this parameter.
(1) Auxiliary
N.O.
Occupied = contact
closed
Unoccupied = contact
open
The output
aligns with
occupancy.
(2) Auxiliary
N.C.
Occupied = contact open
Unoccupied = contact
closed
(3*) This selection option is not used.
(4*) This selection option is not used.
(5) Auxiliary On/Off control through the
auxiliary network command. The output
can be commanded through the network
for any required auxiliary functions via a
separate and dedicated network
variable.
The output
aligns with
the
secondary
network
occupancy
command.
* If option (3) or (4) is selected, the option functions like
option (1) or (2) respectively.
FL time Sets the maximum actuator stroke
timing (floating ContrlTyp
TEC2627-4 model).
Default: 1.5 min
Range: 0.5 to 9.0 min (adjustable in 0.5 minute increments)
Cph Sets the maximum number of
cycles per hour (on/off CntrlTyp
TEC2627-4 model).
Default: 4
Range: 3 to 8 cycles per hour
RA/DA Choice of reverse or direct acting
analog output signal (TEC2647-4
model).
Default: DA
(RA): Reverse acting, 0 to 100% = 10 to 0 VDC
(DA): Direct acting, 0 to 100% = 0 to 10 VDC
Table 4: Installer Configuration Menu (Part 5 of 6)
