Johnson Controls TEC-3620 User Manual

FlexSys Thermostat Zone Controller / LCD Touch Screen
TEC - 3620
Model:
©2016 Johnson Controls | The performance specications are nominal and conform to acceptable industry standards. For applications at conditions beyond these specications, consult the local
Johnson Controls ofce. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
© 2016 AirFixture, LLC
10
Installation / Operation Manual
V160919
TEC3000 Series On/Off or Floating Fan Coil and Zoning Thermostat Controllers with Dehumidification
Capability Installation Instructions
Note: VAV and 2-pipe systems should connect their
valve to the heating output.
Figure 12: Floating Control
(Pressure-Dependent VAV)
Room Temperature Control Thermostat
(Minimum and Maximum Position
Adjusted on Actuator)
Floating
Actuator
COS
COM
24V
HTG O
HTG C
F
I
G
:
m
o
d
e
l
_
1
_
c
l
n
g
_
o
n
l
y
Figure 13: Floating Control
(Pressure-Dependent VAV with Changeover Sensor/Switch)
FIG:model_1_htng_clng_chngvr
Changeover
Sensor
Room Temperature Control Thermostat
(Minimum and Maximum Position
Adjusted on Actuator)
Floating
Actuator
Supply Air
Temperature Sensor
COS
COM
24V
HTG O
HTG C
Figure 14: Floating Control
(Pressure-Dependent VAV with Changeover Sensor/Switch and Reheat)
FIG:model_1_htng_clng_chngvr_rht
Changeover
Sensor
Room Temperature Control Thermostat
(Minimum and Maximum Position
Adjusted on Actuator)
Heating/Cooling
and On/Off
Duct Heater
Floating
Actuator
Supply Air
Temperature Sensor
1
C
COS
COM
24V
HTG O
HTG C
AUX
AUX

Johnson Controls TEC-3620 Specifications

General

Brand	Johnson Controls
Model	TEC-3620
Category	Controller
Language	English
