Johnson Controls TEC-3620 User Manual

FlexSys Thermostat Zone Controller / LCD Touch Screen
TEC - 3620
Model:
©2016 Johnson Controls | The performance specications are nominal and conform to acceptable industry standards. For applications at conditions beyond these specications, consult the local
Johnson Controls ofce. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
© 2016 AirFixture, LLC
7
Installation / Operation Manual
V160919
TEC3000 Series On/Off or Floating Fan Coil and Zoning Thermostat Controllers with Dehumidification
Capability Installation Instructions
7
Table 2: Terminal Identification (See Figure 10 and Figure 11 for Wiring Diagrams)
Terminal Label Function
TEC3310, TEC3311, TEC3312,
TEC3313 Floating FC/VAV and
On/Off FC
1
TEC3610, TEC3611, TEC3612,
TEC3613 Floating FC/VAV
and On/Off FC
1
24 V 24 VAC hot from transformer
FAN H Fan high
FAN M Fan medium
FAN L Fan on (single-speed, variable speed), Fan low multi-speed)
AUX Auxiliary binary output
AUX Auxiliary power
COM 24 VAC common from transformer
CLG O Cool open (Floating), Cooling NC (On/Off)
CLG C Cool close (Floating), Cooling NO (On/Off)
HTG O Heat open (Floating), Heating NC (On/Off)
HTG C Heat close (Floating), Heating NO (On/Off)
COM Common
VSF Variable speed fan command (configurable 0 to 10 V range)
BI2 Configurable binary input 2
BI1 Configurable binary input 1
COS Supply temperature sensor
R SEN Zone temperature sensor
NET+ Not connected Field bus+/N2+
NET- Not connected Field bus-/N2-
NET COM Not connected Isolated common for field bus
1. There is no support for an On and Off VAV.

Johnson Controls TEC-3620 Specifications

General

Brand	Johnson Controls
Model	TEC-3620
Category	Controller
Language	English
