Johnson Controls TEC3010 User Manual

TEC3000 Series Wireless Proportional Fan Coil and Individual Zone Thermostat Controllers with Dehumidification
Capability Installation Instructions
39
System Status
(Cont)
Changeover State Supply
Temperature
Unreliable
Changeover Disabled
Cooling Mode
Heating Mode
Supply Temperature Unreliable
Zone Temp Source Internal Sensor Unreliable
Internal Sensor
Remote Sensor
Network Override
Input Not Installed
Control Status Cooling % Command 0% 0 to 100%
Heating % Command 0% 0 to 100%
Reheat % Command 0% 0 to 100%
Cool Stage 1 Off On or Off
Heat Stage 1 Off On or Off
Reheat Stage 1 Off On or Off
Fan % Command 0% 0 to 100%
Fan On On or Off when Supply Fan Type =
Single-speed or Variable-speed
Off, Low, Medium, or High when Supply
Fan Type = Multi-speed
Controller Info Model Name TEC302x-xx
—
Software Version x.x.x.xxxx —
Unit Name TECxxxxx —
Device Name — User-Supplied
Device Description TEC3000
—
Commissioning Supply Air Temperature Display Current
Temperature
—
Heat Command 0% 0 to 100%
Cool Command 0% 0 to 100%
Supply Fan No Yes or No
Aux No Yes or No
Update View Version x.x.x.xxxx Current Release of Software
Load Firmware
— File list from USB drive
Restore
— File list from USB drive or local storage*
*Configuration can be backed up to the
USB drive and restored to like models in
the effort to expedite the commissioning
process.
Backup
— File list from USB drive or local storage*
*Configuration can be backed up to the
USB drive and restored to like models in
the effort to expedite the commissioning
process.
Table 10: Menus and Submenus (Part 7 of 8)
Level 1 Level 2
(LCD Screen Name)
Level 3
(Default Values)
Available Values
