Johnson Controls TEC3011 User Manual

TEC3000 Series Wireless Proportional Fan Coil and Individual Zone Thermostat Controllers with Dehumidification
Capability Installation Instructions
35
Control Setup
(Cont)
Aux Mode Not Used Not Used, Occupied NO, Occupied NC,
Occupied Fan NO, Occupied Fan NC, On,
Off
Load Shed Rate Limit 0.066°F 0 to 1°F (0 to 0.5°C)
Load Shed Adjust 4°F 0 to 8°F (0 to 4°C)
Fan Alarm Delay 0 seconds 0 to 300 seconds
Fan Alarm Action (when Fan Alarm
Delay is greater than 0)
Enable Enable or Shutdown
Fan Alarm Reset (when Fan Alarm
Delay is greater than 0)
No Yes or No
Fan Runtime Limit 0 hours 0 to 9,000 hours
Fan Runtime Reset (when Fan
Runtime Limit is greater than 0)
No Yes or No
Supply Air Temperature Alarm Offset 0°F 0 to 10°F (0 to 5.5°C)
Supply Air Temperature Alarm Delay
(when Supply Air Temp Alarm Offset
is greater than 0)
300 seconds 300 to 3,600 seconds
Unocc Low Speed Fan Disable Enable or Disable
*When Fan Type = Multi-Speed Fan
(only available in versions 2.0.4 or
greater)
Inputs
BI1 Config Disabled Disabled, Open Window, Open Door, Fan
Lock, Service, Dirty Filter, Motion NC,
Motion NO, Temp Occ, Occupancy
BI2 Config Disabled Disabled, Open Window, Open Door, Fan
Lock, Service, Dirty Filter, Motion NC,
Motion NO, Temp Occ, Occupancy
Supply Temp Sensor* Nickel Nickel, Platinum, A99B, 2.25k ohm
negative temperature coefficient (NTC),
10k ohm NTC, 10k ohm NTC Type 3
* Analog and non-four pipe units
Supply Temp Offset* 0 degrees -5 to 5 degrees (°F or °C based on Units
setting under Display Settings menu)
* Analog Sensor
Zone Temp Sensor Nickel Nickel, Platinum, A99B, 2.25k ohm NTC,
10k ohm NTC, 10k ohm NTC Type 3
* Analog Sensor
Zone Temp Sensor Offset 0 degrees -5 to 5 degrees (°F or °C based on Units
setting under Display Settings menu)
Humidity Offset 0% RH -15% to 15% RH
Reset Sensors False True or False
Tuning
Temp Control Setup Automatic PID
Tuning
Automatic PID Tuning, Manual PID
Tuning, Deadband Override
Reset PID Tuning No Yes or No
Table 10: Menus and Submenus (Part 3 of 8)
Level 1 Level 2
(LCD Screen Name)
Level 3
(Default Values)
Available Values
1
