TEC3000 Series Networked and Wireless Proportional Fan Coil and Individual Zone Thermostat Controllers with
Dehumidification Capability Installation Guide
17
Cooling Setpoint
Displays the current cooling setpoint. Indicates that Hold mode is disabled. To
enable Hold mode, press the button.
Heating Setpoint
Displays the current heating setpoint. Indicates that Hold mode is disabled. To
enable Hold mode, press the button.
Setpoint Temperature
Displays the current setpoint temperature. Indicates that the Show Hold button
is set to No.
Heating Mode
Indicates that heating mode is selected.
Cooling Mode
Indicates that cooling mode is selected.
Auto Mode
Indicates that Auto mode is selected.
Fan Overrides for
Single-speed Fans
On
Auto
Quiet
Adjusts the fan override between On, Auto, and Quiet for single-speed fans.
Fan Overrides for
Variable-speed Fans
On
Auto
Quiet
Adjusts the fan override between On, Auto, and Quiet for variable-speed fans.
Table 5: Touchscreen icons (Part 3 of 5)
Icon Icon name Description
To Next Page
