Johnson Controls Tyco PRV-1A - Page 9

TFP1581
Page 9 of 14
Nominal
Valve
Sizes
in.
(DN)
O.D.
Pipe
Size
in.
(mm)
Nominal Installation Dimensions
in.
(mm)
Approx.
Weight
lb
(kg)
A B C D E
2
(50)
2.88
(60,3)
10 3/16
(260)
2.80
(71,1)
11.09
(281,7)
6.28
(159,5)
8.94
(2 27,1)
35.0
(15,9)
3
(80)
3.50
(88,9)
13 3/4
(349)
2.95
(74,9)
12.77
(324,4)
7.78
(197,6)
8.94
(2 27,1)
71.0
(32,2)
4
(100)
4.50
(114,3)
16 3/4
(425)
3.00
(76,2)
14.12
(358,6)
8.44
(214,4)
8.44
(214,4)
106.0
(48,1)
6
(150)
6.62
(168,3)
22 7/16
(569)
4.52
(114,8)
15.41
(391,4)
11.78
(299,2)
10.94
(277,9)
188.0
(85,3)
8
(200)
8.62
(219,1)
27 7/16
(697)
5.29
(134,4)
18.11
(460,0)
14.78
(375,4)
14.44
(366,8)
338.0
(153,3)
Nominal
Valve
Sizes
in.
(DN)
Nominal Installation Dimensions
in.
(mm)
Approx.
Weight
lb
(kg)
A B C D E
3
(80)
13 3/4
(349)
4.00
(101,6)
12.77
(324,4)
7.78
(197,6)
8.94
(2 27,1)
83.0
(37,6)
4
(100)
16 3/4
(425)
4.42
(112,3)
14.12
(358,6)
8.44
(214,4)
8.44
(214,4)
127. 0
(57,6)
6
(150)
22 7/16
(569)
5.41
(137,4)
15.41
(391,4)
11.78
(299,2)
10.94
(277,9)
215.0
(97,5)
8
(200)
27 7/16
(697)
6.76
(171,7)
18.11
(460,0)
14.78
(375,4)
14.44
(366,8)
376.0
(170,6)
B
A
C
D
E
A
C
B
D
E
FIGURE 8
MODEL PRV-1
A PRESSURE REDUCING VALVE
GROOVE x GROOVE END CONNECTIONS
NOMINAL INSTALLATION DIMENSIONS
FIGURE 9
MODEL PRV-1
A PRESSURE REDUCING VALVE
FLANGE x FLANGE END CONNECTIONS
NOMINAL INSTALLATION DIMENSIONS
