Cable mounting on the ground rail
Fig. 11
• Ground wire connected to the ground
rail.
Fig. 12
• Cable screen must be connected to
the ground rail
• Cable screen must be as short as pos-
sible
• Cable screen must be connected
within a distance of 100 mm from the
controller.
Unisab III panel mounting kit
6/6
Mounting instruction - Unisab III
006093 - en 2009.02.
