VA7800 Series Electric Valve Actuators Product Bulletin
8
Technical Specifications
Table 7: VA7810-AGx-2 and VA7810-ADx-2 Series On/Off (Floating) Electric Non-Spring Return Valve
Actuators
Model VA7810-AGx-2 VA7810-ADx-2
Thrust Force 180 lb (800 N) minimum
Power Supply AC 24 V (AC 19 to 30 V) at 50/60 Hz,
Class 2
AC 230 V (AC 195 to 265 V) at 50/60
Hz
Transformer Sizing 3 VA 8 VA
Input Signal AC 24 V (AC 19 to 30 V) at 50/60 Hz AC 230 V (AC 195 to 265 V) at 50/60
Hz
Feedback N/A N/A
Auxiliary Switch Rating Two Single-Pole, Double-Throw (SPDT), AC 230 V, 3.0 A Resistive, 1/4 hp
Stroke 5/16 to 1 in. (8 to 25 mm)
Stroke Speed 5/16 in. stroke: 48 seconds
1/2 in. stroke: 76 seconds
3/4 in. stroke: 114 seconds
Ambient Operating Conditions 23 to 131°F (-5 to 55°C); 10 to 90% RH Noncondensing
Enclosure Rating NEMA 2 (IP54)
Electrical Connection 48 in. (1.2 m) UL 758 Type AWM Halogen Free Cable with 18 AWG
(0.85 mm
2
) Conductors and 0.25 in. (6 mm) Ferrule Ends
Dimensions 9.6 x 4.56 x 8.35 in. (244 x 116 x 212 mm)
Materials Gearbox and Yoke Die Cast Aluminum
Cover Resin ABS/PC - UL94-V0
Stem Stainless Steel
Coupler Brass
Life Cycles 100,000 full stroke cycles
Shipping Weight 5.4 lb (2.5 kg)
Compliance United States UL 60730 Listed Type 1 Enclosure, CCN XAPX, File E194024
Canada UL 60730-1 Listed Type 1 Enclosure, CCD XAPX7, File E194024
Europe CE Mark - Johnson Controls, Inc. declares that this product is in compliance
with the essential requirements and other relevant provisions of the
EMC directive and the Low Voltage Directive.
