VA9208-GGx-x Series Proportional Electric Spring Return Valve Actuators Installation Instructions 3
Dimensions
Valve Actuator
See Figure 2 and Table 1 for valve actuator
dimensions.
Table 1: VA9208 Actuated VG1241, VG1245, VG1841, and VG1845 Series Ball Valve Dimensions, in. (mm)
Valve Size
in. (DN)
Valve
Style
1
AB CDEFG
1-1/4 (DN32) All 5-5/32
(131)
1-1/32 (26) 1-23/32 (44) 7-1/4
(184)
3-15/16
(100)
11/32 (9) 1-31/32
(50)
1-1/2 (DN40) All 5-5/16
(135)
1-9/64 (29) 1-57/64 (48) 7-7/16
(189)
4-21/64
(110)
11/32 (9) 2-11/64
(55)
2 (DN50) 2-Way 5-17/32
(140)
1-15/32 (37) 2-1/8 (54) 7-11/16
(195)
4-24/32
(123)
11/32 (9) 2-27/64
(62)
3-Way 7-7/8
(200)
1. Port A must always be connected to the coil (Figure 2).
Figure 2: Spring Return VA9208 Actuated VG1241, VG1245, VG1841, and VG1845 Series Ball Valve
Dimensions, in. (mm)
3-29/32
(99)
2-7/8
(73)
Port Marking
Locations
F
I
G
:
V
A
9
2
0
8
X
_
d
i
m
s
3-1/2 (89)
Clearance Required
