型号 / Models VAP600S-24-B/C VAP1000S-24-B/C VAP1000L-24-B/C VAP3000L-24-B/C
控制类型 / Type of Control 比例调节/浮点 / Proportional/Floating
电源 / Supply Voltage 24 VAC/DC ± 15% 50/60 Hz
额定推力 / Nominal Force 600N 1000N 1000N 3000N
额定行程 / Nominal Stroke 30mm 30mm 50mm 50mm
功耗 /
Power Consumption
24VAC 27VA 27VA 27VA 40VA
24VDC 12VA 12VA 12VA 20VA
运行速度 /
Running Speed
高速 / High Speed 1s/mm
低速 / Low Speed 2s/mm
灵敏度 / Sensitivity ≤0.8%
控制信号 / Control Signal 0(2)~10VDC / 0(4)~20mA
阀位反馈信号 / Feedback Signal 0(2)~10VDC / 0(4)~20mA
电压输入阻抗 / Voltage Input Impedance >100KΩ
电流输入阻抗 / Current Input Impedance <0.15KΩ
电压输出负载要求 / Voltage Output Load >2KΩ
电流输出负载要求 / Current Output Load <0.5KΩ
上下极限死区范围 / Up and Down Dead Band ≤2%
防水接头 / Waterproof Connector PG13.5
电气连接 / Electrical Connect 1~6mm
2
线径，接线长度 ≤100m / 1~6mm
2
wire diameter , length≤100m
防护等级 / IP Rating IP65 (EN60529)
工作环境 / Ambient Operating Condition -25°C to 65°C, ≤95% RH, non-condensing / 无凝结水
储藏环境 / Ambient Storage Condition -40°C to 65°C, ≤95% RH, non-condensing / 无凝结水
阀门连接 / Connection to Valves S12 S12 S14 S14
重量（不含包装）/ Weight (excl. packaging) 3.0kg 3.0kg 3.0kg 3.8kg
CE 合规 / CE Compliance
江森自控声明此产品符合以下各项的基本要求和其他相关规定：
Johnson Controls declares that this product is in compliance with the essential
requirements and other relevant provisions of:
EMC 指令 / EMC Directive
2. 执行器技术参数
Actuator technical specifications
性能规格为标称规格，符合可接受的行业标准。要在超出这些规格的条件下使用，请咨询当地 Johnson Controls 办事处。对于因产品误用或滥用而造
成的损失，Johnson Controls 概不负责。
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these specifications,
consult the local Johnson Controls office. Johnson Controls shall not be liable for damages resulting from misapplication or misuse of its products.
