Configuration Guides—XT-9100 Configuration Guide 27
RI. HI. Type R/W Tag Description
07 07 1 Byte R/W DOS1 Digital Output Status XP1
X8 X7 X6 X5 X4 X3 X2 X1
X1 = 1 XP1 : Output 1 is On
X2 = 1 XP1 : Output 2 is On
X3 = 1 XP1 : Output 3 is On
X4 = 1 XP1 : Output 4 is On
X5 = 1 XP1 : Output 5 is On
X6 = 1 XP1 : Output 6 is On
X7 = 1 XP1 : Output 7 is On
X8 = 1 XP1 : Output 8 is On
08 08 1 Byte R/W DOS2 Digital Output Status XP2
X8 X7 X6 X5 X4 X3 X2 X1
X1 = 1 XP2 : Output 1 is On
X2 = 1 XP2 : Output 2 is On
X3 = 1 XP2 : Output 3 is On
X4 = 1 XP2 : Output 4 is On
X5 = 1 XP2 : Output 5 is On
X6 = 1 XP2 : Output 6 is On
X7 = 1 XP2 : Output 7 is On
X8 = 1 XP2 : Output 8 is On
09 09 1 Byte R DIS1 Digital Input Status XP1
X8 X7 X6 X5 X4 X3 X2 X1
X1 = 1 XP1 : Digital Input 1 is On
X2 = 1 XP1 : Digital Input 2 is On
X3 = 1 XP1 : Digital Input 3 is On
X4 = 1 XP1 : Digital Input 4 is On
X5 = 1 XP1 : Digital Input 5 is On
X6 = 1 XP1 : Digital Input 6 is On
X7 = 1 XP1 : Digital Input 7 is On
X8 = 1 XP1 : Digital Input 8 is On
