28 Configuration Guides—XT-9100 Configuration Guide
RI. HI. Type R/W Tag Description
10 0A 1 Byte R DIS2 Digital Input Status XP2
X8 X7 X6 X5 X4 X3 X2 X1
X1 = 1 XP2 : Digital Input 1 is On
X2 = 1 XP2 : Digital Input 2 is On
X3 = 1 XP2 : Digital Input 3 is On
X4 = 1 XP2 : Digital Input 4 is On
X5 = 1 XP2 : Digital Input 5 is On
X6 = 1 XP2 : Digital Input 6 is On
X7 = 1 XP2 : Digital Input 7 is On
X8 = 1 XP2 : Digital Input 8 is On
11 0B 2 Byte R AIS Analog Input Status
X16 X15 X14 X13 X12 X11 X10 X9 X8
X7 X6 X5 X4 X3 X2 X1
X1 = 1 AIH1 High Alarm Condition
X2 = 1 AIL1 Low Alarm Condition
X3 = 1 AIH2 High Alarm Condition
X4 = 1 AIL2 Low Alarm Condition
X5 = 1 AIH3 High Alarm Condition
X6 = 1 AIL3 Low Alarm Condition
X7 = 1 AIH4 High Alarm Condition
X8 = 1 AIL4 Low Alarm Condition
X9 = 1 AIH5 High Alarm Condition
X10= 1 AIL5 Low Alarm Condition
X11= 1 AIH6 High Alarm Condition
X12= 1 AIL6 Low Alarm Condition
X13= 1 AIH7 High Alarm Condition
X14= 1 AIL7 Low Alarm Condition
X15= 1 AIH8 High Alarm Condition
X16= 1 AIL8 Low Alarm Condition
