Configuration Guides—XT-9100 Configuration Guide 29
RI. HI. Type R/W Tag Description
12 0C Number R AI1 Analog Input Value 1
13 0D Number R AI2 Analog Input Value 2
14 0E Number R AI3 Analog Input Value 3
15 0F Number R AI4 Analog Input Value 4
16 10 Number R AI5 Analog Input Value 5
17 11 Number R AI6 Analog Input Value 6
18 12 Number R AI7 Analog Input Value 7
19 13 Number R AI8 Analog Input Value 8
20 14 Number R/W AO1 Analog Output Value 1
21 15 Number R/W AO2 Analog Output Value 2
22 16 Number R/W AO3 Analog Output Value 3
23 17 Number R/W AO4 Analog Output Value 4
24 18 Number R/W AO5 Analog Output Value 5
25 19 Number R/W AO6 Analog Output Value 6
26 1A Number R/W AO7 Analog Output Value 7
27 1B Number R/W AO8 Analog Output Value 8
28 1C Spare
29 1D Spare
30 1E Spare
31 1F Spare
32 20 4 Bytes R/W CNT1 DI1 Pulse Count*
33 21 4 Bytes R/W CNT2 DI2 Pulse Count*
34 22 4 Bytes R/W CNT3 DI3 Pulse Count*
35 23 4 Bytes R/W CNT4 DI4 Pulse Count*
36 24 4 Bytes R/W CNT5 DI5 Pulse Count*
37 25 4 Bytes R/W CNT6 DI6 Pulse Count*
38 26 4 Bytes R/W CNT7 DI7 Pulse Count*
39 27 4 Bytes R/W CNT8 DI8 Pulse Count*
40 28 Spare
41 29 Spare
42 2A Spare
43 2B Spare
44 2C Spare
45 2D Spare
46 2E Spare
47 2F Spare
* Pulse Count Items are stored in EEPROM upon power failure and restored to RAM upon
power restoration.
