30 Configuration Guides—XT-9100 Configuration Guide
RI. HI. Type R/W Tag Description
48 30 1 Byte Int CNF PC1 Prescaler DI1 Counter
49 31 1 Byte Int CNF PC2 Prescaler DI2 Counter
50 32 1 Byte Int CNF PC3 Prescaler DI3 Counter
51 33 1 Byte Int CNF PC4 Prescaler DI4 Counter
52 34 1 Byte Int CNF PC5 Prescaler DI5 Counter
53 35 1 Byte Int CNF PC6 Prescaler DI6 Counter
54 36 1 Byte Int CNF PC7 Prescaler DI7 Counter
55 37 1 Byte Int CNF PC8 Prescaler DI8 Counter
56 38 1 Byte CNF DIL1 Internal use only
57 39 1 Byte CNF DIL5 Internal use only
58 3A 1 Byte CNF DIL9 Internal use only
59 3B 1 Byte CNF DILD Internal use only
60 3C 1 Byte CNF DOL1 Internal use only
61 3D 1 Byte CNF DOL5 Internal use only
62 3E 1 Byte CNF DOL9 Internal use only
63 3F 1 Byte CNF DOLD Internal use only
64 40 1 Byte CNF DIT1 Digital Input Type XP1
X8 X7 X6 X5 X4 X3 X2 X1
X1 = 0 XP1 : DI1 = Maintained Contact
X1 = 1 XP1 : DI1 = Pulse Contact
X2 = 0 XP1 : DI2 = Maintained Contact
X2 = 1 XP1 : DI2 = Pulse Contact
X3 = 0 XP1 : DI3 = Maintained Contact
X3 = 1 XP1 : DI3 = Pulse Contact
X4 = 0 XP1 : DI4 = Maintained Contact
X4 = 1 XP1 : DI4 = Pulse Contact
X5 = 0 XP1 : DI5 = Maintained Contact
X5 = 1 XP1 : DI5 = Pulse Contact
X6 = 0 XP1 : DI6 = Maintained Contact
X6 = 1 XP1 : DI6 = Pulse Contact
X7 = 0 XP1 : DI7 = Maintained Contact
X7 = 1 XP1 : DI7 = Pulse Contact
X8 = 0 XP1 : DI8 = Maintained Contact
X8 = 1 XP1 : DI8 = Pulse Contact
