Configuration Guides—XT-9100 Configuration Guide 31
RI. HI. Type R/W Tag Description
65 41 1 Byte CNF DIT2 Digital Input Type XP2
X8 X7 X6 X5 X4 X3 X2 X1
X1 = 0 XP2 : DI1 = Maintained Contact
X1 = 1 XP2 : DI1 = Pulse Contact
X2 = 0 XP2 : DI2 = Maintained Contact
X2 = 1 XP2 : DI2 = Pulse Contact
X3 = 0 XP2 : DI3 = Maintained Contact
X3 = 1 XP2 : DI3 = Pulse Contact
X4 = 0 XP2 : DI4 = Maintained Contact
X4 = 1 XP2 : DI4 = Pulse Contact
X5 = 0 XP2 : DI5 = Maintained Contact
X5 = 1 XP2 : DI5 = Pulse Contact
X6 = 0 XP2 : DI6 = Maintained Contact
X6 = 1 XP2 : DI6 = Pulse Contact
X7 = 0 XP2 : DI7 = Maintained Contact
X7 = 1 XP2 : DI7 = Pulse Contact
X8 = 0 XP2 : DI8 = Maintained Contact
X8 = 1 XP2 : DI8 = Pulse Contact
66 42 1 Byte CNF DOT1 Digital Output Type XP1
X8 X7 X6 X5 X4 X3 X2 X1
X1 = 0 XP1 : DO1 = ON/OFF Type
X1 = 1 XP1 : DO1 = Pulse Type
X2 = 0 XP1 : DO2 = ON/OFF Type
X2 = 1 XP1 : DO2 = Pulse Type
X3 = 0 XP1 : DO3 = ON/OFF Type
X3 = 1 XP1 : DO3 = Pulse Type
X4 = 0 XP1 : DO4 = ON/OFF Type
X4 = 1 XP1 : DO4 = Pulse Type
X5 = 0 XP1 : DO5 = ON/OFF Type
X5 = 1 XP1 : DO5 = Pulse Type
X6 = 0 XP1 : DO6 = ON/OFF Type
X6 = 1 XP1 : DO6 = Pulse Type
X7 = 0 XP1 : DO7 = ON/OFF Type
X7 = 1 XP1 : DO7 = Pulse Type
X8 = 0 XP1 : DO8 = ON/OFF Type
X8 = 1 XP1 : DO8 = Pulse Type
