32 Configuration Guides—XT-9100 Configuration Guide
RI. HI. Type R/W Tag Description
67 43 1 Byte CNF DOT2 Digital Output Type XP2
X8 X7 X6 X5 X4 X3 X2 X1
X1 = 0 XP2 : DO1 = ON/OFF Type
X1 = 1 XP2 : DO1 = Pulse Type
X2 = 0 XP2 : DO2 = ON/OFF Type
X2 = 1 XP2 : DO2 = Pulse Type
X3 = 0 XP2 : DO3 = ON/OFF Type
X3 = 1 XP2 : DO3 = Pulse Type
X4 = 0 XP2 : DO4 = ON/OFF Type
X4 = 1 XP2 : DO4 = Pulse Type
X5 = 0 XP2 : DO5 = ON/OFF Type
X5 = 1 XP2 : DO5 = Pulse Type
X6 = 0 XP2 : DO6 = ON/OFF Type
X6 = 1 XP2 : DO6 = Pulse Type
X7 = 0 XP2 : DO7 = ON/OFF Type
X7 = 1 XP2 : DO7 = Pulse Type
X8 = 0 XP2 : DO8 = ON/OFF Type
X8 = 1 XP2 : DO8 = Pulse Type
68 44 1 Byte CNF DOPT Digital Output Pulse Time (*5 ms.)
(default = 200)
69 45 1 Byte CNF XTS XT-9100 Type Settings
0 0 0 0 0 X3 X2 X1
X1 = 0 50 Hz Power Line
X1 = 1 60 Hz Power Line
X2 = 0 Output Reset on communication
failure
X2 = 1 Output Hold on communication
failure
X3 Internal use only
70 46 1 Byte CNF Spare
71 47 1 Byte CNF Spare
72 48 1 Byte CNF Spare
73 49 1 Byte CNF Spare
74 4A 1 Byte CNF Spare
75 4B 1 Byte CNF AI2C Internal use only
76 4C 1 Byte CNF AMOD Internal use only
