Configuration Guides—XT-9100 Configuration Guide 33
RI. HI. Type R/W Tag Description
77 4D 1 Byte CNF IOMAP Extension Module I/O Map
X8 X7 X6 X5 X4 X3 X2 X1
X1 = 0 XP1 : I/O1 and I/O2 Not Used
X1 = 1 XP1 : I/O1 and I/O2 Used
X2 = 0 XP1 : I/O3 and I/O4 Not Used
X2 = 1 XP1 : I/O3 and I/O4 Used
X3 = 0 XP1 : I/O5 and I/O6 Not Used
X3 = 1 XP1 : I/O5 and I/O6 Used
X4 = 0 XP1 : I/O7 and I/O8 Not Used
X4 = 1 XP1 : I/O7 and I/O8 Used
X5 = 0 XP2 : I/O1 and I/O2 Not Used
X5 = 1 XP2 : I/O1 and I/O2 Used
X6 = 0 XP2 : I/O3 and I/O4 Not Used
X6 = 1 XP2 : I/O3 and I/O4 Used
X7 = 0 XP2 : I/O5 and I/O6 Not Used
X7 = 1 XP2 : I/O5 and I/O6 Used
X8 = 0 XP2 : I/O7 and I/O8 Not Used
X8 = 1 XP2 : I/O7 and I/O8 Used
78 4E 1 Byte CNF IOTYP Extension Module I/O Type
0 0 0 0 X4 X3 X2 X1
X1 = 0 XP1 : I/O1 and I/O2 Digital
X1 = 1 XP1 : I/O1 and I/O2 Analog
X2 = 0 XP1 : I/O3 and I/O4 Digital
X2 = 1 XP1 : I/O3 and I/O4 Analog
X3 = 0 XP1 : I/O5 and I/O6 Digital
X3 = 1 XP1 : I/O5 and I/O6 Analog
X4 = 0 XP1 : I/O7 and I/O8 Digital
X4 = 1 XP1 : I/O7 and I/O8 Analog
