34 Configuration Guides—XT-9100 Configuration Guide
RI. HI. Type R/W Tag Description
79 4F 1 Byte CNF IOMOD Extension Module I/O Mode
X8 X7 X6 X5 X4 X3 X2 X1
X1 = 0 XP1 : I/O1 and I/O2 Input
X1 = 1 XP1 : I/O1 and I/O2 Output
X2 = 0 XP1 : I/03 and I/O4 Input
X2 = 1 XP1 : I/O3 and I/O4 Output
X3 = 0 XP1 : I/O5 and I/O6 Input
X3 = 1 XP1 : I/O5 and I/O6 Output
X4 = 0 XP1 : I/O7 and I/O8 Input
X4 = 1 XP1 : I/O7 and I/O8 Output
X5 = 0 XP2 : I/O1 and I/O2 Input
X5 = 1 XP2 : I/O1 and I/O2 Output
X6 = 0 XP2 : I/O3 and I/O4 Input
X6 = 1 XP2 : I/O3 and I/04 Output
X7 = 0 XP2 : I/O5 and I/O6 Input
X7 = 1 XP2 : I/O5 and I/O6 Output
X8 = 0 XP2 : I/O7 and I/O8 Input
X8 = 1 XP2 : I/O7 and I/O8 Output
80 50 1 Byte CNF Spare
81 51 1 Byte CNF Spare
82 52 1 Byte CNF Spare
83 53 1 Byte CNF Spare
84 54 1 Byte CNF Spare
85 55 1 Byte CNF Spare
86 56 2 Byte CNF MTBC Maximum Time Between
Communications (default = 60 sec.)
87 57 2 Byte CNF AOT Analog Output Type
X16 X15 X14 X13 X12 X11 X10 X9
X8 X7 X6 X5 X4 X3 X2 X1
X2 X1
Signal Analog Output 1
= 00 Output Disabled
= 01 Output 0 to 10V
= 10 Output 0 to 20 mA
= 11 Output 4 to 20 mA
X4 X3 Signal Analog Output 2 (as X2 X1)
X6 X5 Signal Analog Output 3 (as X2 X1)
X8 X7 Signal Analog Output 4 (as X2 X1)
X10 X9 Signal Analog Output 5 (as X2 X1)
X12 X11 Signal Analog Output 6 (as X2 X1)
X14 X13 Signal Analog Output 7 (as X2 X1)
X16 X15 Signal Analog Output 8 (as X2 X1)
