Configuration Guides—XT-9100 Configuration Guide 35
RI. HI. Type R/W Tag Description
88 58 2 Bytes CNF AIT1 Input Type of Analog Input 1
0 0 0 0 0 X11 X10 X9
X8 X7 X6 X5 X4 X3 X2 X1
X4 X3 X2 X1
Unit of Measure
= 0000 No Units
= 0001 Degrees Celsius or Kelvin
= 0010 Degrees Fahrenheit
= 0011 Percent
X5 = 1 Enable Square Root of Input
X6 = 1 Alarm on Unfiltered Value
X7 = 0 0-10 Volts
X7 = 1 0-2 Volts, 0-20 mA or RTD
X8 = 1 20 % Suppression
X11 X10 X9 Linearization and Sensor Type
= 000 Linear (active sensor)
= 001 Nickel 1000 (JCI)
= 010 Nickel 1000 Ext. Rng
= 011 A99 Sensor
= 100 PT1000 Sensor
89 59 Number CNF HR1 High Range Analog Input 1
90 5A Number CNF LR1 Low Range Analog Input 1
91 5B Number R/W (E) HIA1 High Alarm Limit Analog Input 1
92 5C Number R/W (E) LOA1 Low Alarm Limit Analog Input
93 5D Number R/W (E) ADF1 Differential on Alarm Limit [units]
94 5E Number CNF FTC1 Filter Constant Analog Input 1
95 5F 2 Bytes Spare
96 60 2 Bytes CNF AIT2 Input Type of Analog Input 2 (bits
as AIT1)
97 61 Number CNF HR2 High Range Analog Input 2
98 62 Number CNF LR2 Low Range Analog Input 2
99 63 Number R/W (E) HIA2 High Alarm Limit Analog Input 2
100 64 Number R/W (E) LOA2 Low Alarm Limit Analog Input 2
101 65 Number R/W (E) ADF2 Differential on Alarm Limit [units]
102 66 Number CNF FTC2 Filter Constant Analog Input 2
103 67 2 Bytes Spare
To Next Page
